Machine Features:
1. 304 Stainless Steel Hygienic Structure
All product-contact parts are made of food-grade 304 stainless steel, offering excellent corrosion resistance and long-term durability while meeting hygiene requirements for food and seafood processing.
2. Waterproof & Easy-to-Clean Body Design
The machine body features a waterproof construction that allows for direct washing and simplifies daily maintenance, ensuring stable and clean production conditions.
3. Advanced PLC Control System
Equipped with a high-performance PLC control system and user-friendly touch screen interface, operators can easily adjust parameters, monitor machine status, and manage recipes with minimal training.
4. Reliable Pneumatic Components
High-quality pneumatic components are used throughout the system to ensure stable operation, precise action control, and extended service life under continuous production.
5. Flexible Mechanical Transmission System
Designed for versatile applications, the mechanical transmission structure allows easy adaptation to various types of filling systems—solid, liquid, paste, powder, or granules—making it suitable for seafood, meat, sauces, pickles, and prepared foods.
Products Specification:
| Model | WHZK10-120 | WHZK10-160 | WHZK10-200 | WHZK14-100 |
| Bag size(mm) | W:70-130 L:80-180 | W:70-160 L:80-210 | W:90-230 L:100-300 | W:55-100 L:100-300 |
| Pack speed | 50-80 bags/min | 45-80 bags/min | 30-60 bags/min | 80-110 bags/min |
| Dimension(mm) | 2400x1380x1750 | 2950x1500x1750 | 2630x1520x1750 | 2700x1600x1750 |
| Filling range | 10g-150g | 10g-250g | 20g-3500g | 10g-120g |
| Machine weight | 2400KG | 2550KG | 2950KG | 3100KG |
| Power(not including vacuum pump) | 4.5KW | 4.5KW | 4.5KW | 4.5KW |
| Air consumption | 0.5 cube/min | 0.5 cube/min | 0.5 cube/min | 0.6cube/min |
| Programmable controller | Frequency converter | Solenoid valve | Servo motor | Inner cam roller bearing |
| Siemens | Delta | FESTO | Delta | IKO |
Products Pictures:
