Versatile Feeding System: The machine uses a track - type feeding method. This design allows it to handle both long boards and multiple short boards simultaneously. Notably, when joining short boards, there is no need to insert spacers between them, which simplifies the operation process and improves production efficiency. Additionally, an automatic stacking system can be added at the discharging end, further streamlining the post - joining material handling process.
High - Speed Production: It offers an impressively high production speed, capable of completing one panel joint in just 2 minutes. This rapid processing time enables manufacturers to handle large - scale production tasks efficiently, meeting tight deadlines and increasing overall output.
Material - Saving: With a sanding amount of less than 0.7mm, this machine is highly material - efficient. Through precise joining technology, it reduces the amount of material that needs to be sanded off after joining. Over time, this results in significant savings in raw materials. For example, if a factory processes a certain amount of panels, it can save approximately 42.866 cubic meters of raw materials annually (calculated based on specific production volumes). Considering the cost of raw materials (e.g., if the board price is 6000 yuan per cubic meter), this amounts to a substantial cost - saving of around 258,000 yuan per year.
Automated and Cost - Effective: It features a high - level of automation, which not only reduces the reliance on manual labor but also enhances the consistency and quality of the joining process. The automation also helps in saving glue, as the machine can precisely control the amount of glue applied during the joining operation. Overall, it contributes to cost - reduction in multiple aspects, including labor, materials, and glue, thereby increasing the profit margin for manufacturers.
Remote - Service - Enabled: Equipped with a wireless transmission module, the machine supports remote maintenance and remote system operation. This allows technicians to troubleshoot and optimize the machine's performance without being physically present, minimizing downtime and ensuring continuous production.
| Model | CGPB - 45PZL - CM | CGPB - 58PZL - CM | CGPB - 48PZL - CM | CGPB - 80PZL - CM | CGPB - 90PZL - CM | CGPB - 110PZL - CM |
|---|---|---|---|---|---|---|
| Workbench Size (mm) | 2500x1300 | 2500x1300 | 3200x1300 | 4200x1300 | 5000x1300 | 6000x1300 |
| Joining Thickness (mm) | 8 - 50 | 10 - 80 | 10 - 50 | 10 - 80 | 10 - 50 | 10 - 50 |
| Upper Pressure (t) | 20 | 20 | 20 | 30 | 40 | 50 |
| Back Pressure (t) | 25 | 38 | 28 | 50 | 50 | 60 |
| Overall Dimensions (mm) (L)x(W)x(H) | 8700x2300x3500 | 8700x2300x3500 | 11250x2300x3500 | 14250x2300x3500 | 16110×2300×3500 | 19650x2300x3500 |
| Weight (t) | 6.8 | 7.0 | 8.4 | 9.4 | 15.4 | 18 |
| Feeding Mode | Auto | Auto | Auto | Auto | Auto | Auto |
