Fully Automated Production: High efficiency with minimal manual intervention.
Energy-Saving & Low Noise: Optimized for eco-friendly and quiet operation.
High Speed & High Yield: Maximizes productivity with reliable performance.
Wide Applications: Ideal for toys, food, beverages, pharmaceuticals, chemicals, pesticides, detergents, and other plastic packaging industries. Produces oil bottles, pesticide bottles, cosmetic bottles, wide-mouth containers, hot-fill bottles, etc.
Cost-Effective: Low investment, quick returns, and easy operation/maintenance.
Comprehensive after-sales service: Installation, debugging, training, and full warranty coverage.
Trusted Quality: A reliable and worry-free choice for your production needs.
Versatility: Handles diverse shapes and sizes (5ml–15L).
Advanced Technology: Hydraulic system and automation ensure precision.
Industry-Proven: Widely adopted across multiple packaging sectors.
| Category | Parameter | Specification |
|---|---|---|
| Basic Info | Model | HT-100 |
| Applicable Materials | PE, PP | |
| Theoretical Output (Idle Cycle) | 100 pcs/hour (varies by design) | |
| Product Capacity | 1 cavity: 5L–100L | |
| Number of Modules | 1 | |
| Number of Stations | 2 | |
| Extrusion System | Screw Diameter | 100mm |
| Screw L/D Ratio | 25:1 | |
| Screw Speed | 80 r/min | |
| Plasticizing Capacity | 145 kg/h | |
| Screw Heating Zones | 4 | |
| Barrel Capacity | 9L | |
| Mold | Max. Extruder Diameter | 400mm |
| Mold Heating Zones | 4 | |
| Number of Cavities | 1 cavity | |
| Mold Platen Spacing | 450–1200mm | |
| Clamping Force | 300 kN | |
| Power | Power Supply | 220/380V, 3-phase, 50/60Hz |
| Total Heating Power | 25 kW | |
| Main Motor Power | 22 kW | |
| Screw Motor Power | 30 kW | |
| Utilities | Water Source | Cooling Tower |
| Air Pressure | 0.6–0.8 MPa | |
| Low-Pressure Air Compressor (Required) | 1 unit (1.0m³/1.0MPa) | |
| Auxiliary Equipment | Crusher | 1 unit (Model: 65) |
| Mixer | 1 unit (Capacity: 200kg) |
