Dual-Station High Efficiency
Dual-mold stations enable continuous cyclic production, achieving up to 1,100 pieces/hour (1,000ml capacity).
Integrated automatic trimming and flash removal system reduces labor costs by 70%.
Advanced Extrusion & Plasticizing
Equipped with a 55mm screw (25:1 L/D ratio) and stepless speed regulation (10-80r/min), delivering 50kg/h plasticizing capacity for uniform melt.
Configurable 1/2/4-cavity molds for flexible production (e.g., 1 cavity for 2L or 4 cavities for 200ml containers).
Energy Efficiency & Stability
Consumes only 7kW average power with optimized hydraulics, saving 30% energy versus conventional models.
50KN clamping force and balanced center-load mold design enhance durability and stability.
Intelligent Control
PLC and touchscreen interface for real-time parameter adjustments, fault diagnostics, and user-friendly operation.
| Parameter | Specification |
|---|---|
| Model | YF-55-2L |
| Applicable Materials | PE, PP, AS, etc. |
| Theoretical Output | 1100 pcs/h (1000ml) |
| Product Capacity | 1 cavity 2L / 2 cavities 500ml / 4 cavities 200ml |
| Number of Dies | 1/2/4 pieces |
| Number of Stations | 2 |
