Simple and Robust Structure: The structure of the universal crushing equipment is simple and sturdy. It runs smoothly and can achieve excellent crushing effects.
Convenient Discharge and Particle Size Adjustment: The crushed materials can be directly discharged from the grinding chamber of the main machine. The particle size can be adjusted by replacing sieves with different pore sizes.
Hygienic Design: The entire crusher is made of stainless steel. The inner wall of the crusher housing is machined to be smooth, which solves the problems of rough inner walls and powder accumulation in previous models. This design ensures that the production of pharmaceuticals, food, chemicals, etc. can better meet national standards and comply with GMP requirements.
| Model | Main Structural Dimensions (mm) | Production Capacity | Feed Particle Size | Discharge Mesh Size | Spindle Speed | Machine Weight | Total Power | ||
|---|---|---|---|---|---|---|---|---|---|
| L | W | H | Kg/H | mm | mesh | rpm | Kg | KW | |
| MR - 20 | 650 | 820 | 1500 | 20 - 150 | <6 | 12 - 120 | 4650 | 230 | 4 |
| MR - 30 | 700 | 900 | 1650 | 30 - 350 | <10 | 12 - 120 | 3800 | 330 | 7.5 |
| MR - 40 | 750 | 1000 | 1750 | 50 - 450 | <12 | 12 - 120 | 3400 | 430 | 11 |
| MR - 50 | 850 | 1150 | 1900 | 80 - 550 | <15 | 12 - 120 | 2900 | 700 | 18.5 |
| MR - 60 | 950 | 1250 | 2150 | 100 - 800 | <15 | 12 - 120 | 2300 | 900 | 22 |
| MR - 80 | 1100 | 1400 | 2250 | 120 - 1000 | <20 | 12 - 120 | 1800 | 1200 | 30 |
| MR - 100 | 1300 | 1500 | 2400 | 150 - 1500 | <20 | 12 - 120 | 1400 | 1800 | 45 |
Simple and Robust Structure: The structure of the universal crushing equipment is simple and sturdy. It runs smoothly and can achieve excellent crushing effects.
Convenient Discharge and Particle Size Adjustment: The crushed materials can be directly discharged from the grinding chamber of the main machine. The particle size can be adjusted by replacing sieves with different pore sizes.
Hygienic Design: The entire crusher is made of stainless steel. The inner wall of the crusher housing is machined to be smooth, which solves the problems of rough inner walls and powder accumulation in previous models. This design ensures that the production of pharmaceuticals, food, chemicals, etc. can better meet national standards and comply with GMP requirements.
| Model | Main Structural Dimensions (mm) | Production Capacity | Feed Particle Size | Discharge Mesh Size | Spindle Speed | Machine Weight | Total Power | ||
|---|---|---|---|---|---|---|---|---|---|
| L | W | H | Kg/H | mm | mesh | rpm | Kg | KW | |
| MR - 20 | 650 | 820 | 1500 | 20 - 150 | <6 | 12 - 120 | 4650 | 230 | 4 |
| MR - 30 | 700 | 900 | 1650 | 30 - 350 | <10 | 12 - 120 | 3800 | 330 | 7.5 |
| MR - 40 | 750 | 1000 | 1750 | 50 - 450 | <12 | 12 - 120 | 3400 | 430 | 11 |
| MR - 50 | 850 | 1150 | 1900 | 80 - 550 | <15 | 12 - 120 | 2900 | 700 | 18.5 |
| MR - 60 | 950 | 1250 | 2150 | 100 - 800 | <15 | 12 - 120 | 2300 | 900 | 22 |
| MR - 80 | 1100 | 1400 | 2250 | 120 - 1000 | <20 | 12 - 120 | 1800 | 1200 | 30 |
| MR - 100 | 1300 | 1500 | 2400 | 150 - 1500 | <20 | 12 - 120 | 1400 | 1800 | 45 |
