Unique Blade Structure: The WSGP crusher features a blade structure that lies between claw blades and flat blades. This design makes it suitable for crushing common plastic products like sheets, pipes, profiles, plates, packaging materials, and plastic injection gate waste. The WSGD flat - type crusher is ideal for recycling plastics such as boxes, thin pipes, blow - molded products, bottles, and shells.
Excellent Granulation and Efficiency: The blade design is optimized, ensuring uniform granulation of the crushed products. These crushers are energy - efficient, durable, and highly cost - effective, which can save electricity during operation.
Adjustable Blade Gap: The gap between the movable and fixed blades can be adjusted, allowing for greater flexibility in the crushing process and better control over the final product size.
Safety - First Design: Multiple safety protection devices are installed to ensure the safety of operators during the operation of the crusher.
Reliable Bearings and Processing: The universal plastic crushers are equipped with sealed bearings, which can maintain smooth rotation of the bearings for a long time. The manufacturing process is mature, and important components such as the crusher housing and the blade holder are integrally processed to ensure high - precision assembly.
| Model | Crushing Aperture (mm) | Crushing Capacity (kg/h) | Fixed Blades (pcs) | Rotating Blades (pcs) | Power | Screen Aperture (mm) | Overall Dimensions (cm) L×W×H | Height of Feeding Port from the Ground H1 (cm) | Net Weight (kg) | |
|---|---|---|---|---|---|---|---|---|---|---|
| kW | HP | |||||||||
| WSGP - 230 | 230×215 | 100 - 150 | 2 | 6 | 4 | 5 | 8 | 97×61×120 | 120 | 290 |
| WSGP - 300 | 310×200 | 150 - 200 | 2 | 9 | 5.5 | 7.5 | 8 | 100×72×129 | 100 | 435 |
| WSGP - 400 | 410×235 | 200 - 250 | 2 | 12 | 7.5 | 10 | 8 | 103×84×139 | 104 | 500 |
| WSGP - 500 | 515×290 | 300 - 350 | 2 | 15 | 11 | 15 | 8 | 123×101×163 | 123 | 900 |
| WSGP - 600 | 610×320 | 350 - 450 | 4 | 18 | 15 | 20 | 8 | 132×111×183 | 137 | 970 |
| WSGP - 800 | 815×470 | 450 - 600 | 4 | 24 | 22/30 (Optional) | 30/40 (Optional) | 10 | 173×149×230 | 172 | 2000 |
| WSGD - 960 | 960×610 | 600 - 800 | 4 | 12 | 37/55 (Optional, 50/75 Optional) | 12 | 258×176×268 | 204 | 3000 |
