Product Specifications
| Model Number | Nominal capacity(ton) | Bin size(L×W×H)(mm) | Mass size(mm) | Matching power(kw) |
| 300 ton (loanword) | 300 | 2000×1100×1000 | 2000×1100×1000 | 22 |
| 2300×1150×1000 | 2300×1150×1000 | |||
| 350 ton (loanword) | 350 | 2200×1100×1000 | 2200×1100×1000 | 30 |
| 400 ton (loanword) | 400 | 2300×1150×1000 | 2300×1150×1000 | 37 |
| 2400×1100×1000 | 2400×1100×1000 | |||
| 500 ton (loanword) | 500 | 2200×1150×1000 | 2200×1150×1000 | 45 |
| 2300×1150×1000 | 2300×1150×1000 | |||
| 2400×1100×1000 | 2400×1100×1000 | |||
| 2500×1100×1000 | 2500×1100×1000 | |||
| 200 ton (loanword) | 200 | 3000×1500×850 | 1500×800 | 2×22 |
| 250 ton (loanword) | 250 | 3700×1500×850 | 1500×800 | 2×30 |
| 315 ton (loanword) | 315 | 3700×1500×850 | 1500×800 | 2×45 |
| 400 ton (loanword) | 400 | 3700×1500×1050 | 1500×700 | 2×45 |
| 630 ton (loanword) | 630 | 4900×1500×1200 | 1500×700 | 2×45 |
Products Features
1. The equipment is hydraulically driven, easy to install, no foundation required;
2. Installation does not require ground screws, in places where there is no power, it can be powered by diesel engine;
3. The form of unloading includes different methods such as flipping, pushing the bag or manually removing the bag;
4. machine dimensions and quality dimensions can be customized according to customer requirements;
5. spherical structure connection between push cylinder and push head, good reliability and long service life of oil seal.
