Specialized Corner Labeling: This machine is specifically designed for corner labeling of boxes. It can apply labels on the upper and side planes of boxes, which is often used for anti - tampering purposes. This feature makes it an essential tool in industries where product security and integrity are crucial.
High - Speed Operation: With an impressive labeling speed, especially for items like playing card boxes, it can label up to 180 pieces per minute. This high - speed performance significantly boosts production efficiency, allowing manufacturers to handle large - scale production tasks with ease.
Secure Label Attachment: The machine ensures that labels adhere firmly to the product surface. For the upper plane of the label, a roller is used for rolling and pressing to ensure a secure attachment. On the side plane, a brush is employed for gentle yet effective pressing, preventing the label from falling off during transportation or storage.
Stable Conveyance: It is equipped with a top - pressing mechanism that enhances the stability of box transportation. This not only ensures smooth movement of products during the labeling process but also contributes to better labeling and relabeling effects, resulting in a more consistent and professional - looking finish.
Intelligent Control System: The machine is equipped with an automatic photoelectric tracking system. It can detect the presence of products and only applies labels when a product is present, effectively preventing label waste. This intelligent feature helps to reduce costs and increase the overall efficiency of the labeling operation.
Reliable Electrical Control: Comprising a high - quality electrical control system with components such as a Panasonic PLC, Weinview touch - screen, Panasonic needle - shaped photoelectric sensors, and Leuze/Italian Tesa label sensors, the YT - 11600 offers stable operation. This system can support continuous 7x24 - hour operation, making it suitable for high - volume production environments.
| Parameter | Details |
|---|---|
| Model | YT - 11600 |
| Labeling Accuracy | ±0.5mm |
| Applicable Label Length | 10mm - 40mm |
| Label Ejection Speed | 5 - 25m/min |
| Applicable Label Width | 10mm - 40mm |
| Labeling Speed | 50 - 200pcs/min |
| Applicable Product Length | 20mm - 300mm |
| Conveying Speed | 5 - 20m/min |
| Applicable Product Width | 20mm - 200mm |
| Weight | 160kg |
| Applicable Product Height | 10mm - 100mm |
| Power Supply | 220V 50Hz |
| Power | 1.5KW |
| Applicable Label Roll Outer Diameter | φ280mm |
| Air Pressure | 0.4 - 0.6Mpa |
| Applicable Label Roll Inner Diameter | φ76mm |
| Conveyor Belt Direction | From left to right |
| Equipment Dimensions | 17006501550mm |
Applicable Labels: It can work with a variety of labels, including self - adhesive labels, self - adhesive films, electronic supervision codes, and barcodes.
Applicable Products: It is mainly suitable for various types of boxes, such as playing - card boxes, mobile - phone packaging boxes, and other similar products that require corner labeling.
Application Industries: The machine finds extensive use in multiple industries, including packaging and printing, stationery, cosmetics, food, toys, daily chemicals, electronics, and pharmaceuticals. For example, it can be used for anti - tampering labeling on Nestle product boxes, playing - card boxes, and network - card boxes.
