| Specification | ZK3850A | ||
| Workbench | Table size | mm | 1000×1250 |
| Maximum allowable load | kg | 1500 | |
| T-slot size | mm×pcs | 22×7 | |
| Working range | Table travel - X-axis | mm | 1250 |
| Spindle box travel - Y-axis | mm | 1000 | |
| Maximum spindle travel - Z-axis | mm | 270 | |
| Hand arm lifting distance | mm | 750(650) | |
| Distance from spindle end to worktable | mm | 1000 | |
| mm | 0(100) | ||
| Spindle | Tapered hole | Mohs #5 | |
| Speed range | r/min | 5-2000 | |
| Maximum output torque | N.m | 500 | |
| Maximum axial resistance | N | 16000 | |
| Maximum drilling diameter | 0m | φ50 | |
| Maximum tapping diameter | mm | M33 | |
| mm | M24 | ||
| Feed | Cutting feed speed range (stepless) | mm/min | 1-500 |
| Fast-moving | m/min | 8 | |
| m/min | 8 | ||
| m/min | 3 | ||
| Feed motor parameters | N.m | 27 | |
| N.m | 11 | ||
| N.m | 16 | ||
| r/min | 3000 | ||
| r/min | 3000 | ||
| r/min | 3000 | ||
| Positioning accuracy | X axis | mm | 0.06 |
| Y axis | mm | 0.06 | |
| Z axis | mm | 0.07 | |
| Repeat positioning Accuracy | X axis | mm | 0.015 |
| Y axis | mm | 0.015 | |
| Z axis | mm | 0.04 | |
| Machine size | mm | 3760×2750×3162 | |
| Machine Weight | kg | 8500 | |
| CNC system | Optional | ||
Products Features
1: High-Precision Hole Machining: The ZK3850A drilling machine offers exceptionally high hole spacing accuracy, ensuring the precise location of each machined hole, making it suitable for various demanding hole system machining tasks.
2: Stable Performance: The machine adopts an advanced CNC system and a robust structural design, ensuring stability and reliability during prolonged high-intensity operations.
3: Versatile Applications: Suitable for machining various materials such as steel and cast iron, the machine efficiently handles hole systems with diameters below 50 mm, making it widely applicable in the production of tube sheet parts.
4: Ease of Operation and Maintenance: The user-friendly design and intuitive interface make the machine easy to operate and maintain, reducing operator training time and maintenance costs.
Products Pictures
