Machine Features:
High-Sensitivity Detection:
Detects ferrous, non-ferrous, and stainless steel contaminants with stable accuracy.
Phase Tracking Technology:
Automatically maintains detection stability even with product effect changes.
Product Auto-Learning:
Automatically adjusts parameters for different materials to reduce false rejects.
DSP Digital Processing:
Provides fast, reliable, and consistent signal analysis.
Large Product Memory:
Supports storage of more than 52 product profiles.
IP66 Industrial Protection:
Dustproof, waterproof, and suitable for wet and harsh production environments.
Food-Grade Conveyor:
Complies with international sanitation standards for direct food inspection.
Anti-Vibration Design:
Maintains accuracy even under strong vibration and electrical interference.
Products Specification:
| Item | Details |
| Model | EJH-360 |
| Type | Conveyor Tunnel Metal Detector |
| Operating Frequency | 10 kHz |
| Sensitivity | Detects ferrous, non-ferrous, stainless steel |
| Material | SUS304 for detector, stainless steel frame |
| Search Coil Diameter | 12 cm |
| Power Supply | 110V/60Hz or 220V/50Hz |
| Belt Material | Food-grade PU/PVC |
| Conveyor Belt Length | 1500 mm |
| Conveyor Height | 750 mm ± 100 mm (adjustable, with wheels) |
| Alarm Mode | Sound + Light |
| Rejection System | Pusher / Air Jet / Drop Down |
| Waterproof Level | IP66 |
| Flow Speed | 25 m/min fixed or 10–40 m/min adjustable |
| Flow Direction | L→R or R→L (optional) |
| System Language | English / Spanish |
| Power Consumption | 90W / 120W / 200W |
| Application | Food, pharmaceuticals, chemicals, toys, garments, recycling lines |
Products Pictures:
