Product Features:
1: High-accuracy servo filling system
Servo motor control ensures precise and consistent filling for every bottle.
2: Dual-line alternating filling
Two channels switch back and forth, significantly boosting productivity for continuous operation.
3: Photoelectric intelligent control
Fills 6–12 bottles per cycle. No bottle, no filling—enabling smart automation.
4: Full SUS316L sanitary-grade contact parts
All liquid-contact parts and tank made of SUS316L stainless steel for hygiene and corrosion resistance.
5: CIP Cleaning System
Product tank equipped with level sensor and rotary spray ball for convenient CIP cleaning.
6: Bottle-neck gripper system
Bottle neck positioning device ensures accurate nozzle-to-bottle alignment, preventing splashing or misalignment.
Technical Parameter
| Number of filling Nozzle | 6 / 8 / 12 |
| Container Volume | 200~5000ml |
| Container Dimension | 30mm-85mm |
| Container Height | 100mm-240mm |
| Accuracy | +/- 0.5% |
| Power Supply | AC380V |
| Power | 3500W |
| Air Pressure | 0.5-0.7MPa |
| Dimensions | 2400mm(L) x 1700mm(W) x 2821 mm(H) |
