Product Features:
1: Supports various cap types
Works with most round caps and pump-action caps. Optional automatic cap sorter and cap feeder.
2: Continuous capping operation
No need for bottle stop. Capping is done while bottles move, significantly increasing throughput.
3: Servo-driven torque & positioning
Capping force and orientation precisely controlled for consistent sealing performance.
4: European motion controller
High-precision actuator ensures accurate cap pick & place operations.
5: Modular head design (1–4 heads)
Expandable based on speed requirements. Flexibly meets production capacity demands.
6: Silicone-lined gripping jaws
Prevent slipping and cap surface damage during high-speed capping.
7: High productivity
Production speed up to 80 bottles per minute; system effectiveness exceeds 98%.
Technical Parameter
| Cap Size | Ø15-Ø60mm |
| Container Dimension | 40mm～100mm |
| Container Height | 80～240 mm |
| power Supply | 380V/50HZ |
| power | 16KW |
| Air Pressure | 0.5～0.7MP |
| Air Consumption | 1500L/min |
| Dimensions | 3270mm(L) x900(W) x 2260 mm(H) |
| Weight | 1500 KG |
