High-Speed Shrink Packaging Machine
This high-speed automatic shrink packaging machine integrates full-sealed reciprocating sealing with continuous shrink wrapping, delivering exceptional performance for medium to large-scale production lines. It supports packaging speeds of up to 80 packs per minute and handles PO
Specifications
- Weight
- Sealer: 600 kg; Shrink tunnel: 600 kg
- Film Type
- POF heat shrinkable film
- Max Speed
- 10–80 packs/min
- Air Pressure
- ≤ 0.5 MPa (5 bar)
- Power Supply
- 380V / 50–60Hz / 3 phase
- Sealing Type
- Full-sealed, reciprocating high-speed sealing
- Conveyor Type
- Chain conveyor, roller sleeve silicone tube, Teflon mesh belt
- Max Film Size
- 630 mm (width) × 280 mm (outer diameter)
- Control System
- Touch screen HMI, PLC control, temperature controller
- Conveyor Speed
- Variable, up to 40 m/min
- Sealing System
- Reciprocating sealing + side sealing; alloy sealing knife with Teflon coating
- Working Height
- 780–850 mm
- Machine Material
- Carbon steel
- Power Consumption
- 13.5 kW
- Max Packaging Size
- 500(L) × 400(W) × 125(H) mm
