AseanMachine Selected
Automatic Box Erecting Sealing Machine
This fully automatic unpacking, packing, and sealing machine is designed for large-scale packaging lines. It integrates carton erecting, product packing, sealing, and in-box detection into a fully unmanned workflow. Equipped with high-precision control and stable mechanical struc
Specifications
- Item
- Details
- Model
- CPM-15
- Air Pressure
- 0.6 MPa
- Power Supply
- AC380V, Three-phase, 50Hz
- Machine Weight
- 2500 kg
- Main Materials
- Aluminum alloy, carbon steel, stainless steel
- Air Consumption
- ＜1 m³/hour
- Carton Size Range
- Min: 220×150×120 mm；Max: 500×400×400 mm
- Power Consumption
- 7.5 kW
- Machine Dimensions
- 5200×1600×2400 mm
- Actual Production Speed
- ≤24 cartons/min (depending on packing quantity)
- Theoretical Max Capacity
- 300 boxes/hour
