Handheld 3-in-1 Fiber Laser Welding/Cutting/Cleaning Machine
This handheld fiber laser welding machine offers high-efficiency metal welding, cutting, and surface cleaning in a portable and compact design. Equipped with customizable fiber cable lengths, a stable dual-temperature water cooling system, and a high-precision 1070–1080nm laser s
Specifications
- Item
- Details
- Model
- LW Series Handheld Metal Fiber Laser Welding Machine
- Chiller
- Dual-temperature & dual-control constant temperature water cooling system
- Fiber Length
- 7m / 10m (standard), 15m customizable
- Power Options
- 1500W / 2000W / 3000W
- Welding Speed
- 0–120mm/s
- Machine Weight
- 120–160kg
- Working Voltage
- 220V / 380V, 50Hz
- Laser Wavelength
- 1070–1080nm
- Working Environment
- 5–40°C, humidity <70%, non-condensing
- Maximum Power Consumption
- < 5kW
- Applicable Plate Thickness
- 0.6–8mm
