Blue-Laser Handheld 3D Scanner
This high-precision 3D scanner features dual scanning modes—blue laser and infrared structured light—offering exceptional accuracy for objects of all sizes. With up to 0.02 mm laser accuracy, fast scanning speeds, 24-bit full-color capture, and advanced algorithms for human body
Specifications
- IMU
- Built-in
- Device Size
- 215×50×74 mm
- Input Power
- 12V 2A
- Laser Class
- Class I (Eye Safe)
- Device Weight
- 372 g
- Data Interface
- Type-C / USB 3.0
- Output Formats
- OBJ / STL / PLY
- Scanning Modes
- Blue Laser (7-line laser) / NIR Infrared Structured Light
- Calibration Board
- High-precision glass calibration board
- Wireless Scanning
- Supported with upcoming accessories
- Operating Humidity
- 0–90% RH
- White LED Lighting
- 12 LEDs
- 3D Resolution (NIR)
- 0.1–2 mm
- Accuracy (NIR Mode)
- ≤0.1 mm
- 3D Camera Resolution
- 1920×1200
- Color Mapping (Blue)
- Supported
- Infrared Marker LEDs
- 12 LEDs
- Scanning Speed (NIR)
- Up to 20 fps
- System Compatibility
- Windows / macOS
- Accuracy (Blue Laser)
- ≤0.02 mm @ 100 mm
- Operating Temperature
- −10°C ~ 40°C
- Working Distance (NIR)
- 170–1000 mm
- Alignment Method (Blue)
- Marker-based
- Alignment Methods (NIR)
- Marker / Geometry / Texture
- Working Distance (Blue)
- 150–400 mm
- 3D Resolution (Blue Laser)
- 0.02–2 mm
- Minimum Scan Volume (Blue)
- 5×5×5 mm
- Single Capture Range (NIR)
- 930×580 mm @ 1000 mm
- Scanning Speed (Blue Laser)
- Up to 60 fps
- Single Capture Range (Blue)
- 270×170 mm @ 300 mm
