AseanMachine Selected
Handheld Industrial 3D Laser Scanner
This high-resolution handheld industrial 3D laser scanner is designed for precise and efficient three-dimensional data acquisition across a wide range of professional applications. Using advanced CMOS-based optical scanning technology and a rotatable scanning structure, it delive
Specifications
- Input
- USB 3.0
- Box Size
- 560×440×310 mm
- Brightness
- 80–95 lm
- Scan Model
- Fixed
- Light Color
- White / Blue / Full Color
- Scan Pixels
- 6.3 million* 2 Black/White/Colorful
- Light Source
- White / Blue / Full Color LED
- Power supply
- DC 12V±0.6V
- Refresh Rate
- 120Hz
- Output Format
- OBJ / STL / ASC / PLY / 3MF / P3
- Equipment Size
- 450×200×100 mm
- Humidity Range
- 10%-90%
- Point Distance
- 0.05-0.4 mm
- Splicing Method
- Fully Automatic Splicing/Marker Points Splicing/Manual Splicing
- Operating system
- Win10, Win11(64-Bit)
- Texture Scanning
- YES
- Turntable Bearing
- 50Kg /100 Kg
- Z Axis Resolution
- 0.05mm@500mm
- Operation Distance
- 350 mm
- X/Y Axis Resolution
- 0.07mm@500mm
- Operation Temperature
- 0-40℃
- Single Measurement Area
- 300×180 mm
- Single Measurement Time
- <1s
- Single Turn Measurement Speed
- ≤50s
