3kg Mechatronics Robot Training System
This Industrial 4.0 robot trainer integrates a 6-axis industrial robot, PLC control system, feeding unit, linear conveyor, visual modules, stamping and gluing simulation, and multi-process automation stations. It is designed for universities and vocational institutions to provide
Specifications
- Color
- Industrial Grey
- Volume
- 1.1 CBM
- Weight
- 128 kg
- Package
- Fine plywood box
- Software
- Robot programming & debugging software (supports online & offline programming, advanced editing, second development API)
- PLC Specs
- 24VDC CPU, digital I/O, analog I/O, multi-network support
- Robot Type
- 6-axis industrial robot training platform
- Application
- Universities, vocational colleges, engineering labs, automation training centers, skills competitions
- Input Power
- Single-phase 220V ±10%, 50Hz
- Core Systems
- 6-axis robot system, PLC system, linear transmission unit, feeding unit, die-casting simulation unit, geometric path module, tool replacement system, electrical control cabinet
- Machine Size
- 1600mm × 1200mm × 1000mm
- Model Number
- ZM7101T
- Product Name
- Industrial 4.0 Robot Trainer / Visual Robot Trainer
- Load Capacity
- 3 kg
- Device Capacity
- < 1.5 kVA
- Training Functions
- Robot programming, PLC wiring & control, electrical circuit design, sensor configuration, pneumatic control, process simulation, assembly tasks
- Working Environment
- -10°C to +40°C, ≤85% RH (25°C), altitude <4000m
- Included Accessories
- Robot tools, grippers, vacuum unit, positioning tools, cables, sensors, pneumatic modules, simulation parts
- Communication Interfaces
- USB, Ethernet, industrial network ports, sensor/actuator connections
