Conveyor Belt Weighing Load Cell
This IP68-rated belt bending beam load cell is designed for high-precision industrial weighing applications, including belt scales, hopper scales, floor scales, and blending systems. With C3 accuracy, low non-linearity, and stable output, it ensures reliable performance under har
Specifications
- Item
- Details
- Type
- Belt Bending Beam Load Cell / Weight Sensor
- Cable
- 4-wire shielded, 0.5–3 m (Red: Exc+, Black: Exc–, Green: Sig+, White: Sig–)
- Material
- Alloy steel or stainless steel
- Applications
- Belt scales, hopper scales, floor scales, blending systems, weighing mounts, custom weighing solutions
- Rated Output
- 2.0 ± 0.002 mV/V
- Non-linearity
- ±0.02% F.S
- Safe Overload
- 150% F.S
- Accuracy Class
- C3
- Creep (30 min)
- ±0.016% F.S
- Rated Capacity
- 5 / 10 / 20 / 30 / 40 / 50 / 75 / 100 / 150 / 200 / 250 / 300 / 500 kg
- Input Impedance
- 400 ± 10 Ω
- Destructive Load
- 200% F.S
- Output Impedance
- 351 ± 2 Ω
- Protection Level
- IP68
- Operating Temperature
- –10°C to +40°C
- Recommended Excitation
- 4–12 VDC (Max 15 VDC)
