Long-Endurance VTOL Fixed-Wing Drone
The Long-Endurance Vertical Fixed-Wing Drone is a professional VTOL UAV designed for long-duration industrial missions such as mapping, surveying, and aerial inspection. It combines the high endurance of fixed-wing aircraft with the flexibility of multi-rotor drones, achieving up
Specifications
- Item
- Description
- Compass
- RM3100 industrial-grade magnetic compass, dual-antenna orientation
- Material
- Composite lightweight body with high stiffness and durability
- Wing Span
- 2.2 m
- Drone Type
- Industrial-grade VTOL (Vertical Take-Off and Landing) fixed-wing UAV
- Flight Mode
- Vertical take-off, horizontal flight, precise landing
- Product Name
- Long-Endurance Vertical Fixed-Wing Commercial Drone
- Cruising Speed
- 23 m/s
- Endurance Time
- Up to 125 minutes per charge
- Operation Mode
- One-button take-off and landing; intelligent flight control
- Propeller Type
- 5-propeller configuration
- Assembly Design
- Foldable arms and V-tail; 1-minute quick assembly/disassembly
- Landing Accuracy
- Within 20 cm (automatic landing)
- Payload Capacity
- 1 kg
- Positioning System
- RTK centimeter-level positioning with Beidou/GPS/GLONASS/Galileo compatibility
- Maximum Flight Speed
- 30 m/s
- Application Scenarios
- Mapping, surveying, inspection, environmental monitoring, industrial surveillance
- Transmission Frequency
- 2.4 GHz
- Maximum Wind Resistance
- 10 kg
- Maximum Take-off Altitude
- 5000 m
- Weight (Excluding Battery)
- Approx. 5 kg
- Maximum Transmission Distance
- 23 km
