Portable MOPA Fiber Laser Marking Machine
This portable MOPA fiber laser marking machine is designed for high-speed, high-precision surface engraving on metals, stone, plastics, acrylic, and other materials. With marking speeds up to 8000mm/s, fast positioning, and superior beam quality, it delivers fine, clean, and stab
Specifications
- Item
- Details
- Laser Type
- MOPA Fiber Laser
- Wavelength
- 1064 nm
- Peak Current
- 15 A
- Input Voltage
- ±15 VDC
- Marking Speed
- 8000 mm/s
- Signal Interface
- Digital XY2-100
- Positioning Speed
- 10000 mm/s
- Storage Temperature
- -10℃ – +60℃
- Marking Power Options
- 20W / 30W / 50W
- Operating Temperature
- 0℃ – 45℃
- Maximum Scanning Angle
- ±15°
- Small Step Response Time
- ≤ 0.4 ms
- Average Operating Current
- 2.0 A
- Marking Area (Field Lens)
- 110×110 mm – 200×200 mm
- Lens Center Distance (X/Y)
- 13.5 mm
- Position Signal Scale Factor
- 0.33 V/°
- Position Signal Input Impedance
- 10KΩ ± 1%
