Portable Raman Spectrometer
The Portable Micro Atomic Absorption Bench Raman Spectrometer is designed for fast, accurate micro-sample analysis across a wide spectral range of 190–1100 nm. With a minimum sample capacity of only 0.5 μL, high-resolution wavelength accuracy of 1 nm, and rapid 5-second measureme
Specifications
- Item
- Spcification
- Model
- BK-CW1000
- Detector
- 3648-pixel linear CCD array
- Test Time
- 5 s
- Net Weight
- 2.5 kg
- Consumption
- 24 W
- Light Source
- Xenon flash lamp
- Power Supply
- AC110/220V ±10%, 50/60 Hz
- Test Accuracy
- 0.1–5 Abs. ±0.1; 5–80 Abs. ±2%
- Absorbance Range
- 0.02–300 (10 mm)
- Whole Wavelength
- 190–1100 nm
- Package Size (WDH)
- 310 × 310 × 310 mm
- Absorbance Accuracy
- 0.02
- External Size (WDH)
- 200 × 130 × 136 mm
- Scanning Wavelength
- 190–850 nm
- Wavelength Accuracy
- 1 nm
- Standard Accessories
- Driver software (1 pc), Power line (1 pc), Power adapter (1 pc)
- Absorbance Resolution
- 0.002 Abs (1 mm)
- Wavelength Resolution
- ≤0.3 nm
- Minimum Sample Capacity
- 0.5 μL
- Ultromicro Optical Distance
- 1 mm / 0.2 mm
- Sample Test Platform Material
- 304 stainless steel & quartz
