YX-40A Flipping Rolling-Shear Beveling Machine
The YX-40A Rolling Shear Flipping Beveling Machine is a high-efficiency, dual-direction plate beveling system designed for industrial metal processing. It features a reducer-driven transmission system, delivering stable power output and superior energy efficiency. Unlike conventi
Specifications
- Weight
- 250 kg
- Motor Power
- 2200 W
- Motor Speed
- 1450 r/min
- Feed-in Speed
- 1.5–2.4 m/min
- Motor Voltage
- 380V 50Hz
- Machine Dimensions
- 800 × 510 × 1070 mm
- Maximum Slope Width
- 15 mm
- Width of Groove Travel
- 1.5–2.4 m/min
- Steel Plate Groove Angle
- 25°–45° (arbitrary adjustment)
- Groove Steel Plate Thickness
- 9–40 mm
- Minimum Clamping Plate Width
- ≥ 80 mm
