XONJE XJ-L300Z Desktop Visual Milling Splitting Machine
Suitable for cutting PCB stamp holes, curved PCBs, and irregular PCBs. Widely used in industries such as automobiles, power supplies, computers, home appliances, mobile phones, connectors, LED, etc
Specifications
- Weight
- 150 kg
- Spindle tool
- 0.8–3.0 mm
- Cutting speed
- 0–100 mm/s
- Spindle speed
- 0–60,000 RPM
- Control method
- Patented software + industrial computer + servo
- Partition area
- 300 × 300 mm
- Working voltage
- 220V AC
- Cutting accuracy
- ±0.02 mm
- Cutting function
- Straight line, L-shape, U-shape, arc, full circle
- External dimensions
- 720 mm (L) × 880 mm (W) × 980 mm (H)
- Positioning accuracy
- ±0.01 mm
- Vacuum suction method
- Upper suction / lower suction
- Number of workstations
- Desktop single workstation
