GUANGDONG XIANGJIE INTELLIGENT TECHNOLOGY CO., LTD
XONJE XJPP-5A Dual-Head Multi-Station Pulse Welding Machine
Suitable for hot pressing welding between high-density FPC, FFC, PCB, connectors, ink cartridge chip welding, plastic hot pressing riveting and other processes. Widely used in industries such as automobiles, power supplies, computers, home appliances, mobile phones, connectors, p
Specifications
- Weight
- 250 kg
- Working area
- 250 × 300 mm
- Working voltage
- AC 220V
- Working position
- Double head, multi-station
- Working pressure
- 0.5–0.7 MPa (dry air source)
- Hot pressing time
- 0–99 s
- Overall dimensions
- 800 mm (L) × 850 mm (W) × 1450 mm (H)
- Positioning fixture
- Multiple sets
- Temperature setting
- 0–500 °C
- Temperature accuracy
- ±2 °C
- Welding head material
- Rare metal
