Hangzhou Dadian CNC
High-speed and High-precision Vertical Machining Center
High precision VMC, travels 1300×700×700mm, spindle 8000rpm
Specifications
- travel_x_mm
- 1300
- travel_y_mm
- 700
- travel_z_mm
- 700
- table_size_mm
- 1400x700
- repeatability_mm
- 0.005
- spindle_motor_kw
- 15
- spindle_speed_rpm
- 8000
- table_max_load_kg
- 1200
- max_tool_length_mm
- 300
- max_tool_weight_kg
- 8
- tool_change_time_s
- 1.8
- rapid_traverse_x_m_min
- 24
- rapid_traverse_y_m_min
- 24
- rapid_traverse_z_m_min
- 24
- positioning_accuracy_mm
- 0.008
- max_tool_diameter_full_mm
- 78
- tool_changer_capacity_pcs
- 24
- max_tool_diameter_empty_mm
- 120
