Machine Features:
High Torque DC Motor Design:
Ensures strong startup performance and stable airflow under various voltage conditions.
Multi-Voltage Compatibility:
Supports 5V, 12V, and 24V DC input for flexible system integration.
High-Speed Axial Airflow:
Multiple speed options up to 10,000 RPM for efficient ventilation and cooling.
Durable PBT UL 94V-0 Structure:
Frame and impeller made of flame-retardant PBT material with high mechanical strength.
Optimized Fan Blade Design:
PBT + glass fiber blades resist deformation, deliver strong airflow, and reduce operating noise.
Low Noise & Long Service Life:
Precision bearing system provides smooth rotation, low vibration, and extended lifespan.
Efficient Copper Coil Motor:
Pure copper winding and optimized magnetic structure reduce heat generation and current loss.
Stable Electronic Control System:
High-quality PCB design ensures low power consumption and reliable long-term operation.
OEM / ODM Customization Support:
Available for voltage, speed, bearing type, and application requirements.
Products Specification:
| Item | Specification |
| Product Type | DC Axial Cooling Fan |
| Fan Type | Axial Flow Fan |
| Model | DC3510 |
| Power Source | Electric |
| Voltage Options | 5V / 12V / 24V DC |
| Speed Options | 5,000 / 7,000 / 8,000 / 10,000 RPM |
| Current Range | 0.04 – 0.35 A |
| Noise Level | 21 – 34 dB(A) |
| Blade Diameter | 35 mm |
| Mounting Type | Free Standing |
| Bearing Type | Ball Bearing / Sleeve Bearing (Optional) |
| Bearing System | Dual Ball Bearing (Optional) |
| Frame Material | PBT UL 94V-0 |
| Impeller Material | PBT UL 94V-0 |
| Blade Material | PBT UL 94V-0 |
| Weight | 9 g |
| Customization Support | OEM / ODM |
| Warranty | 1 Year |
| Certification | CE / RoHS / FCC / ISO 9001 |
Products Pictures:
