Machine Features:
Industrial Axial Flow Air Exhaust Design:
Optimized airflow direction ensures efficient panel ventilation and heat dissipation.
Strong and Stable Airflow Performance:
High-energy motor structure provides powerful airflow for continuous industrial operation.
Durable Engineering Plastic Structure:
Glass-fiber reinforced PA impeller and PBT housing offer high strength, moisture resistance, and durability.
Precision Bearing System:
Smooth rotation with reduced friction ensures low noise and long service life.
Multiple Speed Options:
Supports different RPM levels to meet various ventilation and cooling requirements.
Wide Voltage Compatibility:
Available in 120V / 220V / 380V AC for different industrial power systems.
Compact Size for Panel Installation:
110 × 110 × 25 mm design allows easy integration into industrial panels and equipment.
Long Service Life Design:
Engineered for long-term operation under continuous working conditions.
OEM / ODM / OBM Customization Support:
Flexible customization for voltage, speed, and application needs.
Products Specification:
| Item | Specification |
| Product Type | AC Axial Flow Fan |
| Application | Panel Ventilation / Exhaust / Cooling |
| Power Source | Electric |
| Voltage Options | 120V / 220V / 380V AC |
| Speed Options | 2300 / 2400 / 2600 / 2700 RPM |
| Mounting Type | Free Standing |
| Bearing Type | Ball Bearing / Sleeve Bearing (Optional) |
| Dimensions | 110 × 110 × 25 mm |
| Weight | 290 g |
| Impeller Material | Glass-Fiber Reinforced PA Plastic |
| Housing Material | Glass-Fiber Reinforced PBT Plastic |
| Blade Material | Plastic |
| Airflow Direction | Exhaust Over Struts |
| Rotation Direction | Counterclockwise (Viewed Toward Rotor) |
| Service Life L10 (40°C) | 80,000 Hours |
| Service Life L10 (Max Temp) | 40,000 Hours |
| Customization Support | OEM / ODM / OBM |
| Warranty | 1 Year |
| After-sales Support | Video Technical Support |
