Machine Features:
Water-Cooled Cooling Structure:
Designed for circulating cooling water systems, suitable for continuous industrial operation.
Accurate Temperature Control:
Provides precise and stable temperature regulation to support consistent production processes.
Wide Industrial Application Compatibility:
Suitable for pharmaceutical, chemical, electronics, and other industrial cooling scenarios.
Efficient Heat Dissipation Design:
Equipped with an all-copper condenser and hydrophilic aluminum foil structure to enhance heat exchange efficiency.
Energy-Efficient & Stable Operation:
Designed to balance cooling performance and energy consumption for long-term industrial use.
Compact and Lightweight Construction:
Space-saving structure allows flexible installation in different industrial layouts.
Isolated Electrical Control Box:
Independent control compartment with good thermal insulation helps protect electrical components and extend service life.
Reliable Mechanical Structure:
Built with durable core components to ensure stable and long-lasting performance.
Products Specification:
| Item | Specification |
| Product Type | Water-Cooled Industrial Chiller |
| Cooling Method | Water-Cooled |
| Function | Circulating Cooling Water |
| Application | Industrial Process Cooling |
| Temperature Control Range | 5 ℃ – 50 ℃ |
| Voltage Options | 220 V / 380 V |
| Power Range | 2.62 – 22 kW |
| Structure Type | Industrial Chiller Unit |
| Core Components | Motor, Bearing |
| Heat Exchange System | All-Copper Condenser |
| Control Method | Electrical Control Box |
| Insulation | Thermal Insulation Design |
| Dimensions (L×W×H) | 870 × 550 × 1000 mm |
| Weight | Approx. 117 kg |
| Operation Mode | Automatic |
| Inspection & Test | Factory Inspection Report Provided |
| Warranty | 1 Year |
Products Pictures:
