Technical specifications:
Specification | VL8S | VL11S | VL12S |
Workbench size | 1000*550mm | 1350*650mm | 1550*650mm |
T-slot (width x number x spacing) | 18*5*100mm | 18*5*114.5mm | 18*5*114.5mm |
Maximum load capacity | 500kg | 1000kg | 1000kg |
X/Y/Z travel | 800/550/550mm | 1120/650/650mm | 1120/650/650mm |
Spindle nose to workbench | 150-700mm | 100-750mm | 100-750mm |
Spindle center to column guide surface | 600mm | 714mm | 714mm |
Double spindle center distance | 410mm | 560mm | 750mm |
Spindle taper bore specifications | BT 40 | BT 40 | BT 40 |
Main motor | 7.5/11/15KW | 7.5/11/15KW | 7.5/11/15KW |
Rotational Speed | 10000/12000rpm | 10000/12000rpm | 10000/12000rpm |
Feed rate | 48m/min | 36m/min | 36m/min |
Positioning accuracy | ±0.004/300 | ±0.004/300 | ±0.004/300 |
Repeat positioning accuracy | ±0.003 | ±0.003 | ±0.003 |
Dimension (L*W*H) approx. | 2600*3000*2850mm | 3100*3250*3100mm | 3200*3250*3100mm |
Weight of the whole machine (approx.) | 7000kg | 9000kg | 9500kg |
