Machine Features:
High Temperature Resistance: Capable of handling inlet air temperatures up to 80°C, suitable for hot or humid climates.
Air-Cooling System: No need for water sources; efficient cooling ensures reliable operation and simplified maintenance.
Stable Dew Point: Maintains outlet air dew point between 3°C–10°C, ensuring consistent dryness.
Low Energy Consumption: Optimized refrigeration cycle and R22 refrigerant deliver superior efficiency and reduced operating costs.
Compact and Durable Design: Lightweight, space-saving structure with corrosion-resistant components for long service life.
Low Pressure Drop: Designed with smooth airflow channels, keeping pressure drop ≤ 0.03 MPa.
Easy Installation and Maintenance: Modular layout and accessible structure for convenient operation and upkeep.
Technical Indicators：
Inlet Temperature: ≤ 80°C
Cooling Method: Air Cooling
Inlet Pressure: 0.4 – 1.0 MPa
Pressure Drop: ≤ 0.03 MPa
Dew Point: 3°C – 10°C
Refrigerant: R22
Product Specifications:
| Model | Air Handling Capacity (Nm³/min) | Power Supply (V/Hz) | Compressor Power (HP) | Fan Power (W) | Air Pipe Diameter | Equipment Weight (kg) | Dimensions (mm) L×W×H |
| XC-0.7HAD | 0.7 | 220/50 | 1 | 45 | ZG1” | 60 | 640×430×580 |
| XC-1HAD | 1.2 | 220/50 | 1 | 90 | ZG1” | 80 | 760×430×700 |
| XC-2HAD | 2.4 | 220/50 | 1 | 150 | ZG1” | 90 | 760×430×720 |
| XC-3HAD | 3.8 | 220/50 | 1.2 | 2×90 | ZG1-1/2” | 150 | 1000×600×860 |
| XC-6HAD | 6.5 | 220/50 | 2 | 2×150 | ZG1-1/2” | 250 | 1200×700×1050 |
| XC-7HAD | 7.5 | 220/50 | 2.6 | 2×150 | ZG1-1/2” | 250 | 1200×700×1050 |
| XC-10HAD | 10.7 | 380/50 | 3.6 | 2×245 | ZG2” | 340 | 1400×800×1130 |
| XC-13HAD | 13.5 | 380/50 | 3.8 | 2×245 | ZG2” | 340 | 1400×800×1130 |
| XC-15HAD | 17 | 380/50 | 3.9 | 4×180 | DN80 | 435 | 1690×850×1658 |
| XC-20HAD | 23 | 380/50 | 4.2 | 2×180+2×245 | DN80 | 480 | 1795×900×1688 |
| XC-25HAD | 27 | 380/50 | 5.5 | 2×180+2×245 | DN80 | 600 | 1970×900×1708 |
| XC-30HAD | 33 | 380/50 | 6.5 | 4×245 | DN80 | 700 | 1810×1010×1908 |
| XC-40HAD | 45 | 380/50 | 8.5 | 2×450–3×245 | DN100 | 820 | 2160×1100×2018 |
| XC-50HAD | 55 | 380/50 | 10.5 | 6×450 | DN125 | 900 | 2350×1190×2250 |
| XC-60HAD | 65 | 380/50 | 13.5 | 5×550 | DN125 | 1100 | 2400×1410×2238 |
| XC-80HAD | 85 | 380/50 | 20 | 4×550+2×870 | DN125 | 1220 | 2200×1550×2600 |
