Product Features:
1: Hydraulic Drive with Strong Folding Force
Provides stable and powerful performance for a wide range of metal sheet folding tasks.
2: Automatic Blade Clamping Function
Once the blade width is adjusted, it clamps automatically when the foot pedal is pressed—no manual button required.
3: Fast Blade Width Adjustment
Blade assembly can be resized quickly in 3–5 seconds, ideal for non-standard sizes.
4: Optional Rear Positioning System
Allows for more precise positioning during production processes.
5: Easy Operation
Simple controls and automated features make it easy to use, even for high-volume tasks.
Product Parameter:
| Parameter | Specification |
| Input Voltage | 3-phase 4-wire 380V |
| Control Voltage | 220V |
| Power | 5.5KW |
| Capacity | 1.0 × 1250mm |
| Machine Size | 1850 × 1100 × 1300mm |
| Table Height | 825mm |
| Machine Weight | 1500KG |
Blade Specification Table:
| Blade Part | Specification |
| Total Length (Lower Blade) | 1250mm |
| Total Length (Upper Blade) | 1200mm |
| Width per Blade Piece | 50cm (customizable) |
