Product Features:
1: Hydraulic Power with Strong Folding Force
Ensures consistent performance and high-precision bending for various sheet sizes.
2: Automatic Blade Clamping
Once the blade width is set, pressing the foot pedal activates automatic clamping — no button required.
3: Fast Blade Width Adjustment
Blade configuration can be changed within 3–5 seconds, making it ideal for non-standard processing.
4: Rear Positioning Optional
Can be equipped with rear positioning for precise backstop alignment during bending.
5: Easy Operation with High Efficiency
Simple control system and quick-change blade setup improve operational speed and reduce downtime.
6: Three-Blade One-Time Forming
This machine uses a three-blade one-time forming blade for efficient bending in a single operation.
Product Parameter:
| Parameter | Specification |
| Input Voltage | 3-phase 4-wire 380V |
| Control Voltage | 220V |
| Power | 5.5KW |
| Capacity | 1.0 × 1250mm |
| Machine Size | 1850 × 1100 × 1300mm |
| Table Height | 825mm |
| Machine Weight | 1500KG |
