Product Features:
1: Hydraulic Power with Strong Bending Force
Designed with a stable hydraulic system, the machine provides sufficient force to handle demanding bending tasks.
2: Automatic Blade Locking System
After adjusting the blade size, there's no need to press any button — the blade automatically clamps when the foot switch is pressed.
3: Quick Width Adjustment for Non-standard Sizes
Blade width adjustment can be completed within 3–5 seconds, improving work efficiency when dealing with variable sizes.
4: Customizable Hinge Blades
Standard blade length is 1250mm (lower) and 1200mm (upper), with 50cm segment width. The hinge section extends up to L28mm, H9mm — fully customizable per customer requirements.
5: User-friendly Operation
Optional rear positioning, fast adjustment, and foot pedal operation make it ideal for high-speed production lines.
6: Movable Lifting Ears on Both Sides
The blades extend into the material to prevent edge deformation during folding.
Product Parameter:
| Parameter | Value |
| Input Voltage | 3 phase 4 wires 380V |
| Control Voltage | 220V |
| Power | 5.5KW |
| Capacity | 1.0 x 1250mm |
| Machine Size | 1850 x 1100 x 1300mm |
| Table Height | 825mm |
| Weight | 1500KG |
Blade Specification Table:
| Part | Specification |
| Lower Blade Length | 1250mm |
| Upper Blade Length | 1200mm |
| Blade Width per Piece | 50cm (customizable) |
| Hinge Blade Size | L ≤ 28mm, H = 9mm (customizable) |
