Machine Features:
1. High-Speed Reciprocating Sealing (Up to 80 packs/min)
Reciprocating motion achieves faster sealing cycles
Perfect for high-volume production environments
Smooth and continuous packaging efficiency
2. Full-Sealed Shrink Packaging System
Complete sealing around the product
Tight, clean shrink finish without openings
Ideal for protective, retail-grade packaging
3. Durable Alloy Sealing Knife with Teflon Coating
Anti-stick, high-temperature resistant
Long service life, stable sealing quality
Prevents film residue, burning, or smoke
4. Large Packaging Compatibility
Handles products up to 500×400×125 mm
Supports POF films up to 630 mm width
Suitable for boxes, bottles, trays, bundles, etc.
5. Intelligent Control System
Touch screen operation
PLC control with adjustable parameters
Precision temperature management for consistent shrinking
6. Variable Speed Conveyor (Up to 40 m/min)
Supports continuous, high-speed workflows
Multiple conveyor options (chain, silicone roller, Teflon mesh)
Stable product transport during sealing and shrinking
7. Industrial-Grade Structure
Carbon steel frame for durability
600 kg sealer + 600 kg tunnel = heavy-duty stability
Built for long-term, intensive production usage
Products Specification:
| Item | Specification |
| Sealing Type | Full-sealed, reciprocating high-speed sealing |
| Power Supply | 380V / 50–60Hz / 3 phase |
| Max Packaging Size | 500(L) × 400(W) × 125(H) mm |
| Max Speed | 10–80 packs/min |
| Film Type | POF heat shrinkable film |
| Max Film Size | 630 mm (width) × 280 mm (outer diameter) |
| Power Consumption | 13.5 kW |
| Conveyor Speed | Variable, up to 40 m/min |
| Conveyor Type | Chain conveyor, roller sleeve silicone tube, Teflon mesh belt |
| Working Height | 780–850 mm |
| Air Pressure | ≤ 0.5 MPa (5 bar) |
| Sealing System | Reciprocating sealing + side sealing; alloy sealing knife with Teflon coating |
| Control System | Touch screen HMI, PLC control, temperature controller |
| Machine Material | Carbon steel |
| Weight | Sealer: 600 kg; Shrink tunnel: 600 kg |
Products Pictures:
