Machine Features:
1. Fully Automatic Sealing & Cutting
Automatic bag feeding, sealing, and cutting
PLC smart control with safety detection
Supports continuous, unmanned packaging
2. High Efficiency Shrink Wrapping
Sealing speed 15–25 pcs/min
Shrink tunnel speed 0–15 m/min
Suitable for both small and large packaging items
3. Adjustable Film System
Adjustable membrane separation plate for dual-layer films
Pin-wheel distance adjustable to match product size
Motorized film pulling for stable and safe operation
4. Intelligent Photoelectric Detection
Imported vertical + horizontal sensors
Automatically detects product size
Prevents empty sealing or wrong sealing
5. Waste Film Collection System
Automatic waste film roll
Keeps working area clean and improves work efficiency
6. Compatible With Production Lines
Can be integrated directly into automated production lines
No additional operators required
Products Specification:
| Item | Sealing & Cutting Unit | Shrink Tunnel |
| Machine Size (LWH) | 1685×828×1480 mm | 1300×700×1465 mm |
| Max. Packing Size | (L) ≤ 500 mm, (W) ≤ 430 mm, (H) ≤ 200 mm | (L) 700 mm, (W) 350 mm, (H) 200 mm |
| Max. Sealing Size | (L) 550 mm × (W) 450 mm | - |
| Working Speed | 15–25 pcs/min | 0–15 m/min |
| Machine Weight | 225 kg | 260 kg |
| Power | 2.5 kW | 9 kW |
| Voltage | 1PH 220V 50Hz | 3PH 380V 50Hz |
| Air Pressure | 6–8 kg/cm² | - |
| Film Material | POF | POF |
Products Pictures:
