Machine Features:
1. 360° Dual-Camera System
Equipped with 1080P HD front and rear cameras supporting 360° horizontal and 180° vertical rotation, the robot provides complete internal pipeline visibility. The low-illumination CMOS sensor ensures clear imaging even in dark or muddy environments, making inspection accurate and efficient.
2. Durable IP68 All-Metal Crawler Design
Built with a waterproof all-metal body and 4×4 crawler drive, the robot performs reliably in wet, uneven, and submerged conditions. The special-shaped anti-skid tires enhance traction, ensuring stable movement and obstacle-crossing ability in complex inspection environments.
3. Smart Control and Measurement System
Integrated with an automatic meter counter and 512 Hz transmitter, the robot offers real-time distance tracking and precise positioning. The panel control supports video recording, photo capture, and playback, while the 40 W adjustable LED lighting provides excellent visibility for all pipeline conditions.
Products Specification:
| Item | Details |
| Product Type | Sewer & Pipeline Inspection Robot |
| Usage | Municipal pipeline, drainage, sewer, and industrial duct inspection |
| Camera Type | 1080P HD dual-camera (front + rear) |
| Camera Rotation | 360° horizontal, 180° vertical |
| Lighting System | 40W adjustable high-brightness LED illumination |
| Drive Type | 4×4 all-wheel drive crawler |
| Body Material | All-metal, anti-corrosion and IP68 waterproof |
| Cable Length | 60 m / 120 m (with 512 Hz signal transmitter) |
| Creeping Mode | Four-wheel independent drive with 3-speed control (high / medium / low) |
| Control Mode | Panel operation with integrated DVR system |
| Functions | Video recording, photo capture, voice recording, and real-time display |
| Data Storage | DVR / memory card |
| Sensor | CMOS |
| Video Compression Format | H.265 |
| Operating Environment | Indoor / outdoor, wet or submerged environments |
| Special Features | Night vision, waterproof, wide-angle lens, meter counting system |
| Weight (approx.) | 20–25 kg (main body + cable reel system) |
| Waterproof Rating | IP68 (full submersion capable) |
| Applicable Industries | Municipal engineering, drainage maintenance, power tunnels, water management, and factory pipelines |
