Machine Features:
• High-Accuracy Pressure Control
– Control accuracy up to 0.1%FS
– Stability reaching 0.005%FS for precise calibration
• Fast Pressure Stabilization
– Reaches stable pressure point within 1–3 seconds
– Improves calibration efficiency and repeatability
• Supports Automatic Calibration
– Suitable for pressure gauges, sensors, and transmitters
– Provides complete automated pneumatic calibration capability
• Multiple Connection & Control Options
– G1/4 pressure port
– RS232 communication for host computer control
– Optional external button operation
• Durable & Easy to Maintain
– Compact design with simple operation
– Supports dry and clean compressed air or nitrogen as the working medium
– IP65 protection design
• Customizable Pressure Range
– Standard range 0–4 MPa
– Supports customized pressure ranges and built-in pressure modules
Products Specification:
| Category | Details |
| Type | Air pressure calibration / pressure control equipment |
| Pressure Range | 0–4 MPa (customizable) |
| Measured Medium | Air / dry clean compressed air / nitrogen |
| Control Accuracy | 0.1%FS |
| Control Stability | 0.005%FS |
| Stabilization Time | 1–3 seconds |
| Connection Port | G1/4 |
| Display | LCD display |
| Gas Source | External air source |
| Load Capacity | 500 mL |
| Protection Level | IP65 |
| Functions | Automatic calibration, RS232 communication, optional external control |
| Operation | Simple operation, compact structure |
| Customized Support | Pressure module customization available |
| Warranty | 1 year |
