Machine Features:
Automatic Lid Folding:
Efficiently folds top flaps and seals cartons without manual intervention.
Handles Wide Carton Range:
Supports carton sizes from small to large with quick manual adjustments.
High-Speed Belt Drive:
Dual-sided bottom belt drive ensures smooth transport at up to 30 m/min.
Stable & Low Noise Operation:
Industrial-grade structure with noise level below 75 dB.
Compatible Tape Options:
Supports multiple tape widths (3.6–7.2 cm) for flexible sealing needs.
Reliable for Continuous Use:
Built for e-commerce, logistics, distribution centers, and manufacturing lines.
Products Specification:
| Item | Specification |
| Model | FZ500K |
| Sealing Speed | 20–35 cases/min |
| Carton Size Range | Min: L200 × W120 × H90 mm；Max: L500 × W400 × H400 mm |
| Belt Speed | 28–30 m/min |
| Compressed Air Supply | 6 kgf/cm²，90 NL/min |
| Table Height | 450 / 600 / 700 mm (customizable) |
| Machine Performance | Automatic lid folding; manual width/height adjustment; dual-side bottom belt drive |
| Tape Width Options | 3.6–7.2 cm |
| Operating Noise | < 75 dB |
| Machine Size | L1650 × W1050 × H1350 mm |
Products Pictures:
Machine Features:
Automatic Lid Folding:
Efficiently folds top flaps and seals cartons without manual intervention.
Handles Wide Carton Range:
Supports carton sizes from small to large with quick manual adjustments.
High-Speed Belt Drive:
Dual-sided bottom belt drive ensures smooth transport at up to 30 m/min.
Stable & Low Noise Operation:
Industrial-grade structure with noise level below 75 dB.
Compatible Tape Options:
Supports multiple tape widths (3.6–7.2 cm) for flexible sealing needs.
Reliable for Continuous Use:
Built for e-commerce, logistics, distribution centers, and manufacturing lines.
Products Specification:
| Item | Specification |
| Model | FZ500K |
| Sealing Speed | 20–35 cases/min |
| Carton Size Range | Min: L200 × W120 × H90 mm；Max: L500 × W400 × H400 mm |
| Belt Speed | 28–30 m/min |
| Compressed Air Supply | 6 kgf/cm²，90 NL/min |
| Table Height | 450 / 600 / 700 mm (customizable) |
| Machine Performance | Automatic lid folding; manual width/height adjustment; dual-side bottom belt drive |
| Tape Width Options | 3.6–7.2 cm |
| Operating Noise | < 75 dB |
| Machine Size | L1650 × W1050 × H1350 mm |
Products Pictures:
