Machine Features:
Integrated Automation:
Combines unpacking, sealing, packing, and palletizing in one system to reduce labor and increase throughput.
High Precision:
±0.04 mm repeated positioning accuracy ensures stable stacking and consistent operation.
Large Working Radius:
1700 mm coverage supports a wide range of pallet formats up to 1200 × 1200 mm.
Efficient Output:
Stacking speed of 6–12 pcs/min enhances productivity for medium and large-scale packaging lines.
Durable Structure:
P54 protection and 0–55°C operating range ensure reliable performance in demanding environments.
Easy Integration:
Communicates via TCP/IP for smooth connection with existing automated production lines.
Compact Footprint:
Requires only 1505 × 1716 mm of floor space, ideal for logistics, warehousing, e-commerce, food, and industrial plants.
Products Specification:
| Item | Specification |
| Load Capacity | 40 kg |
| Working Radius | 1700 mm |
| Maximum Pallet Size | 1200 × 1200 mm |
| Vertical Distance | Fixed H = 1600 mm |
| Stacking Speed | 6–12 pcs/min |
| Repeated Positioning Accuracy | ±0.04 mm |
| Communication Mode | TCP/IP |
| Protection Level | IP54 |
| Operating Temperature | 0–55°C |
| Maximum Power Dissipation | 4 kW |
| Power Supply | Single Phase 220V / 50Hz |
| Machine Weight | ≈ 360 kg |
| Floor Area | 1505 × 1716 mm |
Products Pictures:
