Multi - Frequency Detection: With 4 built - in frequencies, it allows for any dual - frequency combination to conduct real - time synchronous detection. This feature ensures that both iron and steel can be detected accurately, enhancing the detection reliability across different types of metal contaminants.
Automatic Learning Function: The detector can complete the learning process after placing good products twice. It automatically calculates parameters such as phase, eliminating the need for complex manual parameter adjustments. This simplifies the operation and reduces the chance of errors during setup.
Product Effect Suppression: Thanks to its dedicated algorithm for suppressing product effects, it can effectively mitigate the impact of highly saline products on detection accuracy. This ensures consistent and reliable detection results even in challenging product environments.
User - Friendly Operation: It is equipped with a color LCD touch - screen, providing an intuitive and convenient human - machine interface. The screen can display four - frequency data simultaneously, allowing operators to monitor the detection process easily.
Stable and Reliable Design: Using a waterproof variable - speed motor and the overall potting technology for the probe, the entire machine is stable and reliable. It has obtained the SGS IP66 certification, indicating its high - level protection against dust and water, which is essential for long - term operation in industrial environments.
Built - in Frequency Hopping: Its frequency - hopping technology enables it to cope with interference from large - scale electrical equipment like packaging machines on - site. This helps to reduce false alarms, ensuring that the detection results are accurate and reliable.
Flexible Expansion Capability: The metal detector's main board is equipped with an embedded operating system, which supports the expansion of USB, printers, and network communication. This flexibility allows for seamless integration with other production - related equipment and systems.
| Model | VMD - P30 | VMD - P50 | VMD - P100 |
|---|---|---|---|
| Inner Pipe Diameter (mm) | 30 | 50 | 100 |
| Sensitivity | Fe ≥ Φ0.4mm Sus ≥ Φ1.0mm | Fe ≥ Φ0.5mm Sus ≥ Φ1.2mm | Fe ≥ Φ0.8mm Sus ≥ Φ1.5mm |
| Power Supply | AC220V 50 - 60Hz | ||
| Parameter Setting | Automatic learning | ||
| Product Recipe Storage | 200 groups | ||
| Pipeline Pressure | ≤ 1MPa | ||
| Weight (kg) | 150 | 170 | 210 |
| Materials to be Inspected | Fluids, sauces | ||
| Ejection Air Source | ≥ 0.5MPa | ||
| Ejection Method | Ball valve | ||
| Pipeline Material | Teflon | ||
| Human - Machine Interaction | 7 - inch touch - screen | ||
| Operating System | Embedded RTOS | ||
| Protection Level | IP66 | ||
| Equipment Material | SUS304 | ||
| Communication Interfaces | USB, network port, RS232 serial port, RS485, 4G remote (optional), support for unmanned production lines (optional) |
Multi - Frequency Detection: With 4 built - in frequencies, it allows for any dual - frequency combination to conduct real - time synchronous detection. This feature ensures that both iron and steel can be detected accurately, enhancing the detection reliability across different types of metal contaminants.
Automatic Learning Function: The detector can complete the learning process after placing good products twice. It automatically calculates parameters such as phase, eliminating the need for complex manual parameter adjustments. This simplifies the operation and reduces the chance of errors during setup.
Product Effect Suppression: Thanks to its dedicated algorithm for suppressing product effects, it can effectively mitigate the impact of highly saline products on detection accuracy. This ensures consistent and reliable detection results even in challenging product environments.
User - Friendly Operation: It is equipped with a color LCD touch - screen, providing an intuitive and convenient human - machine interface. The screen can display four - frequency data simultaneously, allowing operators to monitor the detection process easily.
Stable and Reliable Design: Using a waterproof variable - speed motor and the overall potting technology for the probe, the entire machine is stable and reliable. It has obtained the SGS IP66 certification, indicating its high - level protection against dust and water, which is essential for long - term operation in industrial environments.
Built - in Frequency Hopping: Its frequency - hopping technology enables it to cope with interference from large - scale electrical equipment like packaging machines on - site. This helps to reduce false alarms, ensuring that the detection results are accurate and reliable.
Flexible Expansion Capability: The metal detector's main board is equipped with an embedded operating system, which supports the expansion of USB, printers, and network communication. This flexibility allows for seamless integration with other production - related equipment and systems.
| Model | VMD - P30 | VMD - P50 | VMD - P100 |
|---|---|---|---|
| Inner Pipe Diameter (mm) | 30 | 50 | 100 |
| Sensitivity | Fe ≥ Φ0.4mm Sus ≥ Φ1.0mm | Fe ≥ Φ0.5mm Sus ≥ Φ1.2mm | Fe ≥ Φ0.8mm Sus ≥ Φ1.5mm |
| Power Supply | AC220V 50 - 60Hz | ||
| Parameter Setting | Automatic learning | ||
| Product Recipe Storage | 200 groups | ||
| Pipeline Pressure | ≤ 1MPa | ||
| Weight (kg) | 150 | 170 | 210 |
| Materials to be Inspected | Fluids, sauces | ||
| Ejection Air Source | ≥ 0.5MPa | ||
| Ejection Method | Ball valve | ||
| Pipeline Material | Teflon | ||
| Human - Machine Interaction | 7 - inch touch - screen | ||
| Operating System | Embedded RTOS | ||
| Protection Level | IP66 | ||
| Equipment Material | SUS304 | ||
| Communication Interfaces | USB, network port, RS232 serial port, RS485, 4G remote (optional), support for unmanned production lines (optional) |
