Product Features:
1: Structural Design – Made of upright columns and steel laminates, ideal for manual storage of lightweight items.
2: Flexible Assembly – Can be used alone or combined freely; simple to assemble and disassemble.
3: Anti-Static Optional – Anti-static function available via powder coating change or rubber mat placement.
4: Shelf Height Adjustability – Each shelf can be adjusted vertically in 50mm increments to meet various usage needs.
5: Stable Connection – Top and bottom shelves are fixed with double angle brackets and screws; middle shelves connected by 8 pins.
6: Mobility Optional – Optional universal casters can be added to enable easy rack transport and repositioning.
Standard Specifications：
| Item | Specification |
| Standard Height (H) | 1500 / 1800 / 2000 mm |
| Standard Width (W) | 1000 / 1200 / 1500 / 1800 mm |
| Standard Depth (D) | 400 / 450 / 500 / 550 / 600 / 650 / 700 mm |
Laminate Description：
Normal Warehouse Rack Laminate
Description: The most widely used rack laminate with a smooth and flat surface.
Application: Ideal for storing small-sized or bulk unpackaged goods.
Pillar Specification & Hole Pattern：
Butterfly Hole Pattern Light-Duty Upright Column
Description: Upright column designed with butterfly-shaped perforated holes.
Application: Suitable for adjustable light-duty shelving with stable support structure.
| Max.Load Bearing | 200kg Layer | 1000kg Integration |
| Material Thickness | T:1.0 | T:1.1 | T:1.35 | T:1.5 |
