Product Features:
1: Using 500 watt-1500 watt fiber laser, high electro-optical conversion efficiency, long laser life, up to 100,000 hours
2: High electro-optical conversion rate, no adjustment, low energy consumption, no consumables, small size, long-term use can save a lot of processing costs for users
3: Aiming at the characteristics of the advertising word industry, the operation is simple and easy to learn, and both students and skilled hands can operate on the machine. Under the current situation that it is difficult to recruit skilled workers and the salary cost has doubled, choosing a laser welding machine can easily solve it for you
4: Large format workbench
Application:
Mainly suitable for welding of stainless steel, carbon steel, alloy steel, silicon steel, spring steel, aluminum, aluminum alloy, galvanized sheet, galvanized sheet and other metals.
Technical Parameter
| Model | UK-HJLX-SC500W | UK-HJLX-SC1000W | UK-HJLX-SC1500W |
| Laser Power | 500w | 1000w | 1500w |
| Laser Wavelength | 1070±5 nm | 1070±5 nm | 1070±5 nm |
| Operation Mode | Continuous/Modulation | Continuous/Modulation | Continuous/Modulation |
| Output Welding Head Type | Handheld swinging head | Handheld swinging head | Handheld swinging head |
| Output Power Stability | ＜3% | ＜3% | ＜3% |
| Power Regulation Range | 10~100% | 10~100% | 10~100% |
| Weld Penetration | 0.5~2.0mm | 0.5~2.0mm | 0.5~2.0mm |
| Spot Width | 0.2-3mm | 0.2-3mm | 0.2-3mm |
| Cooling Method | Built in water cooling | Built in water cooling | Built in water cooling |
| Fiber Optic Cable Length | Standard configuration: 10 meters, MAX15 meters | Standard configuration: 10 meters, MAX15 meters | Standard configuration: 10 meters, MAX15 meters |
| Blowing Protection | Argon, nitrogen | Argon, nitrogen | Argon, nitrogen |
| Power Demand | AC220v/50Hz | AC220v/380v/50Hz | AC380v/50Hz |
| Power | 3.5 Kw | 4.5 Kw | 5.5 Kw |
| Cover An Area | 1*1.6m | 1*1.6m | 1*1.6m |
| Whole Machine Weight | 180 Kg | 200 Kg | 200 Kg |
| Operation Temperature | 0~40°C | 0~40°C | 0~40°C |
| Working Humidity | 10~75% | 10~75% | 10~75% |
| Environmental Requirements | No vibration, no interference source, maintain ventilation | No vibration, no interference source, maintain ventilation | No vibration, no interference source, maintain ventilation |
| Consumables | Purified water, argon gas | Purified water, argon gas | Purified water, argon ga |
