High - speed and Low - noise Operation: The machine can reach a maximum speed of 250 mm/s, and the impact noise is no more than 80 decibels, which is equivalent to normal conversation.
Long - lasting and Efficient Heating: The carbon - fiber heating tubes used in the machine have the characteristics of rapid heating, small thermal lag, and uniform heat generation. Their lifespan (continuous burning) is ≥ 6000 hours. Prolonged operation of this machine can improve blood circulation, accelerate metabolism, and enhance the immune system.
Versatile Function: By changing the mold, the machine can be used for both molding and punching, providing great flexibility in production.
Energy - saving Design: The heating elements of the machine are fully enclosed with heat - insulating cotton. When in standby mode, the external radiation power accounts for only 10% of the heating power, while conventional IMD hot - forming machines on the market have an external radiation power as high as 50%. For example, in hot summer, 10 conventional 4KW IMD devices usually require 10 5P air conditioners, but this machine only needs 2.
Home Appliance Industry: Control and decorative panels for rice cookers, washing machines, microwave ovens, air conditioners, refrigerators, etc.
Electronics Industry: Front covers and nameplates of MP3, MP4, VCD, DVD, calculators, electronic notebooks, digital cameras, etc.
Automotive Industry: Instrument panels, air - conditioning panels, interior parts, lamp housings, logos, etc.
Computer Industry: Keyboard, mouse, and front covers.
Communication Industry: Mobile phone keys, mobile phone lenses, mobile phone color covers, small 灵通 and fixed - phone panels, window lenses.
Other Industries: Medical devices, cosmetic boxes, sports and entertainment leisure products, decorative boxes, toys, etc.
| Model | 10T | 20T | 30T | 40T | 50T | 60T | 100T |
|---|---|---|---|---|---|---|---|
| Maximum Working Pressure of Liquid (MPa) | 10 | 22 | 24 | 25 | 22 | 25 | 26.3 |
| Maximum Opening Distance (mm) | 400 | 400 | 400 | 400 | 400 | 400 | 400 |
| Maximum Stroke of the Slide Block (mm) | 300 | 300 | 300 | 300 | 300 | 300 | 300 |
| Effective Worktable Area (Left - Right, mm) | 600 | 600 | 700 | 700 | 800 | 800 | 800 |
| Effective Worktable Area (Front - Back, mm) | 400 | 400 | 500 | 500 | 600 | 600 | 600 |
| Downward Speed of the Slide Block Pressure Head (mm/s) | ≥100 | ≥100 | ≥100 | ≥100 | ≥100 | ≥100 | ≥100 |
| Working Speed (mm/s) | 15 - 20 | 15 - 20 | 15 - 20 | 15 - 20 | 15 - 20 | 15 - 20 | 15 - 20 |
| Return Speed (mm/s) | ≥100 | ≥100 | ≥100 | ≥100 | ≥100 | ≥100 | ≥100 |
| Height from the Machine Frame Tabletop to the Ground (mm) | 800 | 800 | 800 | 800 | 800 | 800 | 800 |
| Effective Heating Area (Left - Right L, mm) | 600 | 600 | 700 | 700 | 800 | 800 | 800 |
| Effective Heating Area (Front - Back W, mm) | 400 | 400 | 500 | 500 | 600 | 600 | 600 |
| Heating Temperature (°C) | 0 - 150° | 0 - 150° | 0 - 150° | 0 - 150° | 0 - 150° | 0 - 150° | 0 - 150° |
| Servo Motor (KW) | 2.9 | 4.4 | 5.5 | 7.5 | 9 | 9 | 17 |
Safety Protection: Optional safety light curtains can be installed to protect the safety of operators, especially their arms and fingers.
Efficient and Stable Hydraulic System: High - quality shock - proof hydraulic valves are used to reduce noise, and the pressure can be adjusted remotely.
Oil Temperature Cooling: Optional air coolers can effectively reduce the oil temperature, extend the service life of the equipment, and reduce maintenance costs.
Precise Guidance: The special - shaped pressure head and four guide rods improve work stability and enable faster mold replacement.
Digital Control: Standard - equipped with a PLC, industrial touch - screen, and displacement sensors, it realizes digital control and programming of positions.
Flexible Function Selection: It can quickly switch between constant - pressure and constant - stroke functions to meet different product requirements and can perform operations such as pressing, shaping, trimming, stretching, and sizing.
