400mm body, smooth narrow passage
The width of the vehicle is only 400 mm, with a minimum passage width of 600 mm and a rotation radius of 600 mm, suitable for narrow passages; The ground clearance of the car chassis is only 20 mm, making it easy to pass through scenarios such as elevators.
4 navigation options available, with high precision of ± 10 mm
Supports four navigation methods: SLAM, QR code, reflector, and NFL, covering various business navigation needs in different scenarios, such as secondary positioning, high dynamic environments, and non modified environments; ± 10mm high precision, precise in place.
Real time vehicle recognition, stable loading and unloading of goods
Paired with a pallet recognition camera, it supports real-time identification of vehicles, and can achieve stable and efficient loading and unloading of goods even in the absence of fixed slots on the turtle cart wheels on site.
Modular design, flexible customization
Modular vehicle design and assembly, with the ability to customize the height, color, and logo of forks and robots as needed, flexibly adapting to various application scenarios and business needs.
Multiple sensors, 360 ° safety protection
Equipped with various safety devices such as navigation laser, obstacle avoidance laser, 3D camera, safety edge contact, and photoelectric sensors, it comprehensively guarantees 360 ° safety protection during actual operation.
| Product Name | Laser SLAM Floor - type Intelligent Forklift |
| Driving Modes | Automatic Navigation, Hand - held Device Driving |
| Navigation Method | Laser SLAM |
| Pallet Type | Three - bar pattern |
| Rated Load Capacity | 300 kg |
| Load Center Distance | 345 mm |
| Self - weight (Including Battery) | 210 kg |
| Standard Lifting Height | 70+5 mm~90+5 mm |
| Overall Dimensions of the Vehicle (Length × Width × Height, Excluding Fork Tips) | 914x400x1502.5 mm |
| Fork Dimensions (Length × Width × Height, Excluding Fork Tips) | 1220 x (170 + 7) x 75 mm (7 mm wire - slot plate) |
| Outer Width of Forks | 480 x 300 mm |
| Right - angle Stacking Aisle Width for Pallet 1000×1200 (1200 Along Fork Placement) | 300 mm |
| Right - angle Stacking Aisle Width for Pallet 800×1200 (1200 Along Fork Placement) | 1989 mm |
| Minimum Turning Radius | 600 mm |
| Ambient Temperature and Humidity Range | Temperature: 0°C ~ 50°C / Humidity: 10% ~ 90%, No Compression Condensation |
