Machine Features:
No Workpiece Flipping Required – Processes large plates without turning, greatly improving work efficiency.
Cold Cutting Process – No oxidation or deformation on groove surface, ideal for welding inspection and NDT film processing.
Adjustable Cutting Speed – Variable frequency control allows fast or slow processing as needed.
Electric Lifting System – Easy operation with precise height adjustment.
Stable Spindle Locking – Ensures reliable performance during processing and smooth release after completion.
Compact Structure – Easy to operate, maintain, and transport.
Higher Efficiency Than Manual Chamfering – Delivers consistent quality and productivity improvement.
Wide Application Range – Compatible with multiple materials and bevel types.
Products Specification:
| Item | Specification |
| Power Supply | 380V / 50Hz three-phase AC power |
| Machine Size | 1130 × 1110 × 600 mm |
| Wooden Box Size | 1200 × 900 × 1000 mm |
| Weight | 408 kg |
| Total Power | 6.59 kW (Main motor: 3kW × 2, Lift motor: 0.2kW) |
| Spindle Speed | 1500 r/min |
| Processing Groove Speed | 0.7–1.5 m/min (variable frequency adjustable) |
| Thickness of Clamping Plate | 4–80 mm |
| Processing Groove Angle | 0°–78° (adjustable as desired) |
| Knife Disk Model | FMZ88R-80-27-SN12-06T (max bevel width 80 mm) |
| Blade Specification | SNMX1025 (6 square inserts) |
| Groove Type | K/V/X/Y type bevel + upper bevel + 0° side groove |
| Height Adjustment System | Electric lift + elastic floating system |
| Clamping Method | Electric automatic clamping plate |
| Transmission Clamping Assembly | 11 sets of transmission wheels (7 upper + 4 lower) |
| Processing Method | Milling |
| Processing Materials | Carbon steel, stainless steel, alloy steel, cast iron, aluminum plate, etc. |
| Groove Smoothness | Ra3.2–6.3 |
Products Pictures:
