Machine Features:
Solid Tires:
Anti-slip and wear-resistant
Long service life
Suitable for multiple indoor road conditions
Wide-View Mast:
High structural strength
Reduced noise during lifting
Improved forward visibility for safer operation
Sealed Hydraulic Cylinder:
Leak-proof design
Stable lifting performance
Improved energy efficiency
Lithium Battery System:
Large capacity for extended working hours
Stable voltage output
Reduced maintenance compared to lead-acid batteries
Reinforced Forks:
Impact-resistant
High torsion strength
Designed for frequent pallet handling
Comfortable Operator Seat:
Ergonomic seating design
Reduces fatigue during long working periods
Supports continuous warehouse operations
Products Specification:
| Model | Unit | CPD30 | CPD35 |
| Rated lifting capacity | kg | 3000 | 3500 |
| Configuration Number | / | High efficiency | |
| Power type | / | lithium battery | |
| Operator type | / | Seating style | |
| Load center distance | mm | 500 | 500 |
| Lift height | mm | 4210 | 4210 |
| Service weight （include battery） | kg | 4550/4320 | 4860/4665 |
| Overall length (with forks) | mm | 3625 | 3660 |
| Full length (without fork） | mm | 2555 | 2590 |
| Overall width | mm | 1260 | 1260 |
| Fork carriage, ISO2328 standard | / | 3A | |
| Fork dimensions | mm | 1070×125×45 | 1070×125×50 |
| Fork outer distance, maximum/minimum | mm | 1100/250 | 1100/250 |
| Ground clearance, center of wheelbase | mm | 130 | 130 |
| Travel speed (full load/empty load) | km/h | 18/18 | 18/18 |
| Turning radius | mm | 2260 | 2275 |
| Max. gradeability, laden/unladen | % | 20/26 | 18/25 |
| Lithium battery voltage/capacity | V/Ah | 80V205/96V205 | |
| Lithium battery weight | kg | 230 | |
| Service brake/parking brake | / | Hydraulic/Mechanical | |
| Hydraulic/Mechanical | Mpa | 16 | |
Products Pictures:
Machine Features:
Solid Tires:
Anti-slip and wear-resistant
Long service life
Suitable for multiple indoor road conditions
Wide-View Mast:
High structural strength
Reduced noise during lifting
Improved forward visibility for safer operation
Sealed Hydraulic Cylinder:
Leak-proof design
Stable lifting performance
Improved energy efficiency
Lithium Battery System:
Large capacity for extended working hours
Stable voltage output
Reduced maintenance compared to lead-acid batteries
Reinforced Forks:
Impact-resistant
High torsion strength
Designed for frequent pallet handling
Comfortable Operator Seat:
Ergonomic seating design
Reduces fatigue during long working periods
Supports continuous warehouse operations
Products Specification:
| Model | Unit | CPD30 | CPD35 |
| Rated lifting capacity | kg | 3000 | 3500 |
| Configuration Number | / | High efficiency | |
| Power type | / | lithium battery | |
| Operator type | / | Seating style | |
| Load center distance | mm | 500 | 500 |
| Lift height | mm | 4210 | 4210 |
| Service weight （include battery） | kg | 4550/4320 | 4860/4665 |
| Overall length (with forks) | mm | 3625 | 3660 |
| Full length (without fork） | mm | 2555 | 2590 |
| Overall width | mm | 1260 | 1260 |
| Fork carriage, ISO2328 standard | / | 3A | |
| Fork dimensions | mm | 1070×125×45 | 1070×125×50 |
| Fork outer distance, maximum/minimum | mm | 1100/250 | 1100/250 |
| Ground clearance, center of wheelbase | mm | 130 | 130 |
| Travel speed (full load/empty load) | km/h | 18/18 | 18/18 |
| Turning radius | mm | 2260 | 2275 |
| Max. gradeability, laden/unladen | % | 20/26 | 18/25 |
| Lithium battery voltage/capacity | V/Ah | 80V205/96V205 | |
| Lithium battery weight | kg | 230 | |
| Service brake/parking brake | / | Hydraulic/Mechanical | |
| Hydraulic/Mechanical | Mpa | 16 | |
Products Pictures:
