Production Processing:
High standard castings:
The core framework of the equipment adopts high-standard QT500-7 and HT250 castings, and the cast parts are measured by testing instruments after being fired. The framework undergoes precise finite element stress analysis and adopts a stable triangular interconnection design, greatly ensuring stability under high-tonnage impact forces.
High standard welding:
Carbon dioxide shielded welding is used throughout the entire welding process, and full welding process is applied at the welding site to ensure that the welded workpiece is firm and aesthetically pleasing.
Stress relief treatment:
The support table for castings and welding adopts a high-precision temperature-controlled furnace, and undergoes multiple heat treatment processes such as tempering and annealing according to the temperature curve corresponding to the material. After a long period of full-frequency vibration aging treatment, the internal stress of the workpiece is released, ensuring no deformation after long-term use.
Precision machining:
Different fixtures are designed for different workpieces, and high-precision multi-axis machining centers are used to perform precision machining on the workpieces, ensuring consistency in accuracy before and after clamping.
Strict testing:
Using a high-precision micrometer U-meter, combined with a marble platform and a marble square with a longer service life, precise measurements are taken for each workpiece. The processing quality of each workpiece is strictly controlled layer by layer, to ensure that the assembly accuracy of the entire machine meets the standards of high-precision machine tools.
High Quality Spare Parts:
Taiwan HIWIN linear guide、Taiwan TBI motion ball screw、Yaskawa or Sanyo servo motors、Japanese NSK bearing、Taiwan APEX gearbox
Product Specifications:
| ITEM | Unit | MP-A1200 | MP-A1500 |
| Bending length | mm | 1200 | 1500 |
| Plate length | mm | 1250 | 1600 |
| Plate width | mm | 1000 | 1250 |
| Bending height | mm | 120 | 170/300(optional) |
| Min forming size (foursides) | mm | 170×100 | 210×100 |
| Min forming size(one side) | mm | 200 | 230 |
| Min.radius | mm | 1.2 | 1.2 |
| Max.continuous bending speed | S | 0.2 | 0.2 |
| Opening height | mm | 120 | 170 |
| Bending angle | / | 0-360° | 0-360° |
| Max.material thickness | mm | Aluminum plate: 2.0 |
| Coldrolled plate:1.5 |
| Stainless steel:0.8 |
| Control system | / | Star300-LGx |
| Operating system | / | Win7+OS+Pressure Arm |
| Axis | / | Standard 13 axis configuration |
| Machine dimension(LxWxH) | mm | 3000x1500x2050 | 3700x1800x2500 |
| Machine weight | Kg | 6500 | 10000 |
