Machine Features:
1: All parts adopt imported servo motors to ensure the accuracy and stability of the machinery, while maintaining long-term durability.
2: The screw guide rails are imported C5 grade products with high precision, excellent performance, and long service life. The minimum movement setting unit for the Y-axis is 0.005 mm.
3: The fully electric servo bending machine is especially power-saving. Compared with the electro-hydraulic servo type, its electricity consumption is similar to the difference between variable frequency air conditioning and ordinary air conditioning. It automatically adjusts output power according to working conditions and consumes less than 0.5 kW when idle.
4: The machine is green and environmentally friendly, requiring no hydraulic oil and eliminating the pollution caused by waste hydraulic oil.
Back Gauge Structure:
1: The crossbeam is processed with high-quality carbon steel, and the overall structural design is simple, compact, and stable, resulting in fast speed and high accuracy.
2: The standard configuration for the rear material blocking of this machine is X and Y axes, with 2 adjustable blocking fingers.
| ITEM | X-axis | R-axis | Z-axis |
| Positioning speed | 500mm/s | 125mm/s | 700mm/s |
| Repetitive accuracy | 0.01mm | 0.1mm | 0.1mm |
| Positioning accuracy | 0.01mm | 0.1mm | 0.1mm |
| Positioning method | Automatic(servo motor) |
Bending Machine System:
1: Switch between Chinese and English interfaces.
2: Programming is simple and easy to operate, with smooth and seamless interface operations from program, mold, synthesis, programming to bending.
3: 2D graphic programming, display, simulation functions, high-speed acceleration and deceleration algorithms, and other functions.
Machine Specifications:
| ITEM | Unit | Single Cylinder | Dual Cylinder |
| EP12/600 | EP18/800 | EP30/1250S |
| Nominal pressure | Kn | 120 | 180 | 300 |
| Workbench | mm | 600 | 800 | 1250 |
| Column spacing | mm | 520 | 720 | 1160 |
| Throat depth | mm | 200 | 250 | 300 |
| Slide stroke | mm | 120 | 120 | 150 |
| Max.opening height | mm | 420 | 450 | 450 |
| Rear material blocking stroke | mm | 200 | 350 | 500 |
| Max speed of slider operation | mm/s | 200 | 200 | 200 |
| Main motorpower | KW | 5.5*1 | 7.5*1 | 7.0*2 |
| Number of axis | / | 3(Y,X,R) | 3(Y,X,R) | 4(Y1,Y2,X,R) |
| Size(LxWxH) | mm | 1000*970*210 | 1000*970*210 | 1400*120*220 |
| Weight | kg | 1150 | 1800 | 2350 |
