JRUI KF40-2800 Servo Energy-Saving Wide-Body Injection Molding Machine

Product Features:

Clamping Unit

1: Computer simulation and manual calculation with five-pivot toggle design

2: Excellent motion curve for the clamping linkage mechanism ensures smooth and fast operation

3: High rigidity clamping system protects molds and extends overall machine lifespan

4: Wear-free clamping mechanism for better template protection and easier maintenance

5: Self-lubricating copper sleeves ensure continuous and effective lubrication

6: Thickened tie rods improve rigidity and prolong service life

7: Precise mold opening positioning (±2mm) with repeatability within 0.3mm

8: Ejector with forced reset to support special molds

9: Anti-tilt sliding foot design for improved stability and anti-skewing of templates

10: Mixed design of T-slots and code holes for easy clamping

11: Low-pressure mold protection ensures mold safety during operations

12: Ultra-wide platen design meets diverse mold size requirements

13: Rear platen with wear-resistant plate reduces friction during movement

14: European-style ejector mechanism makes thimble maintenance easier

Injection Unit

1: Low resistance design using linear guide rails to reduce injection friction

2: Modular structure design to meet diverse customer demands

3: Bi-injection shift design ensures no nozzle leakage

4: Dual-alloy screw enhances durability and service life

5: German imported sealing components ensure reliable operation

6: Bearing slide design supports smooth motion and easy material changeover

Hydraulic System

1: High-response servo system saves 20–80% energy, operates with fast speed and short response time

2: Optimized oil circuit with plug-in valve plates ensures quick reaction and smooth movement

3: Automatic proportional backpressure for easier and precise process adjustment

4: Differential clamping device offers faster motion and better energy efficiency

5: Imported hydraulic valves provide stable and reliable performance

6: Integrated frame structure minimizes welding, enhances structural strength

7: No-weld design throughout the machine to eliminate leak points

8: Enlarged power system boosts overall operational efficiency

9: Self-sealing suction filter simplifies maintenance and enhances oil filtration reliability

Electrical System

1: Core electrical components from Schneider, Omron, and other reliable imported brands

2: Generalized program design to accommodate various application needs

3: Encoder directly connected to thrust seat for precise position control

4: Separation of strong and weak electrical systems ensures safer operation

Product Parameter:
